Customer’s ‌requirements:

·       Valve function and connection: On-off, Buttweld type

·       Valve size and pressure: 6″, Class 150

·       Medium parameters: LNG (Liquefied Natural Gas), -175~+60℃

·       Actuator: Manual gear

Miwival’s ‌solution:

·       Valve type: Ball valve, Buttweld, 6″, Class 150

·       Valve material: Body: F304L, Trim: F316, Seat: PCTFE, Stem: XM-19

·       Actuator: Manual gear

·       Available functions: Fire-proof design, Special materials and extend stem for cryogenic fluid
